XHT750 Mini Mixer Dump Truck Specifications

XHT750 Mini Mixer Dump Truck Specifications

Recruiting Distributors and Agents Worldwide!
ProductsCategory:Mini Mixer Dump Truck
ProductsKeyword: --
Specifications:CE Certification, Euro 5 Certification, ISO 9001

Phone:+8615092753270

Email:admin@xinghangmachinery.com

Product Details

Contents

Product Introduction

  1. Equipped with a tracked mobility system, it features low ground contact pressure and excellent adaptability to various terrains, enabling stable operation even on rugged, muddy, or soft surfaces.

  2. Equipped with a professional mixing device featuring a rationally designed blade system, it ensures thorough mixing of materials, achieving uniform dispersion of concrete or other components to guarantee optimal mixing quality.

  3. Integrating mixing and transportation functions reduces labor costs and enhances work efficiency.

  4. The vehicle's operational control system is designed with user-friendly features, featuring a rational layout of controls and buttons that facilitate easy operation and mastery by the driver.

  5. It features high mixing speed and efficiency, enabling the completion of concrete mixing in a relatively short time, thereby enhancing construction productivity.

  6. The structure of small tracked mixer trucks is relatively simple, with fewer components, making maintenance and upkeep easier while reducing repair complexity and costs.

Product Parameters


Model

XHT750

Key dimension

Engine

Net weight

774kg

Power Model

Bailitong 25T2

Maximum load capacity

750kg

Power Source Type

Single-cylinder air-cooled four-stroke engine

Tank volume

300dm3

Chassis width

850mm

Total displacement (ML)

420CC

Crawler width

180mm

Rated power (HP/rpm)

13.5HP/3600rpm

Crawler grounding length

1000mm

Fuel Type

92 # Gasoline

Chassis ground clearance

110mm

Fuel tank volume

6.5L

Tipping method

Hydraulic dump truck

Engine options

Tip angle

90°

Bailitong 25T2 / Kepu l92 / Honda GX390 / Runtong 420cc            (For details on the remaining engines, please consult separately.)

Chopper bucket length

820mm

Leakage outlet length

300mm

Size

Leakage outlet width

150mm

Overall dimensions of the machine

2500*900*1500mm

Walking Performance and Speed

5km/h

Tank dimensions

φ720*880mm

Least radius of gyration

1300mm

Packing measurement

Crawler center distance

670mm

Fumigation-free wooden box packaging

2230*1090*1520mm

Climbing capacity

20°

Steel frame stacking packaging

2250*960*2560mm
